Technical Features:
1. Simple structure,reliable and stable performance of the whole machine, simple operation and maintenance, Replacing product specifications is simple.
2.Adopt Japan's Mitsubishi PLC hardware to ensure the operation of the machine.
3.The overall performance of the machine is strong,and it can work more than 20 hours a day.
4.The PLC program is written by our seniorengineers who have been in the industry formore than 10 years.
5.The measuring cup system used is developed by our company.
6.The servo motoradopts the Japanese Panasonic brand.
7.The touch screen operation is simple and intuitive.
8.Important electronic components are imported brands.
9.Intelligent photoelectric tracking,accurate bag positioning.
10.Fully automatic completion of feeding, bag making, The whole process of sealing and product outputis completed at onetime.
11.The packing speed can besetfreely.
12.This machine meets the national GMP requirements.
Technical Features:
1. Simple structure,reliable and stable performance of the whole machine, simple operation and maintenance, Replacing product specifications is simple.
2.Adopt Japan's Mitsubishi PLC hardware to ensure the operation of the machine.
3.The overall performance of the machine is strong,and it can work more than 20 hours a day.
4.The PLC program is written by our seniorengineers who have been in the industry formore than 10 years.
5.The measuring cup system used is developed by our company.
6.The servo motoradopts the Japanese Panasonic brand.
7.The touch screen operation is simple and intuitive.
8.Important electronic components are imported brands.
9.Intelligent photoelectric tracking,accurate bag positioning.
10.Fully automatic completion of feeding, bag making, The whole process of sealing and product outputis completed at onetime.
11.The packing speed can besetfreely.
12.This machine meets the national GMP requirements.
Scope of application:
medicine, food, chemical industry, cosmetics, desiccant and other Industries Small bag packaging of powder, granule, liquid, paste and other materials
Main technical parameters:
|
Baglength |
50-200mm(L) |
|
Bagwidth |
4 columns of 20-50mm, 6 columns of 20-50mm, 8 columns of 20-35mm, 10 columns of 20-30mm(customizable) |
|
Maximum width offilm |
880mm(customizable) |
|
Packingspeed |
20-40 bag/min/lane |
|
Measurement range |
0.5--30g |
|
Air pressure |
0.6mpa |
|
Airconsumption |
0.8m3/min |
|
Voltage |
AC380V/50HZ |
|
Power |
6.5KW |
|
Dimensions |
(L)1680mm×(w)1300mm×(H)3000mm |
|
Machine weight |
800kg |
Scope of application:
medicine, food, chemical industry, cosmetics, desiccant and other Industries Small bag packaging of powder, granule, liquid, paste and other materials
Main technical parameters:
|
Baglength |
50-200mm(L) |
|
Bagwidth |
4 columns of 20-50mm, 6 columns of 20-50mm, 8 columns of 20-35mm, 10 columns of 20-30mm(customizable) |
|
Maximum width offilm |
880mm(customizable) |
|
Packingspeed |
20-40 bag/min/lane |
|
Measurement range |
0.5--30g |
|
Air pressure |
0.6mpa |
|
Airconsumption |
0.8m3/min |
|
Voltage |
AC380V/50HZ |
|
Power |
6.5KW |
|
Dimensions |
(L)1680mm×(w)1300mm×(H)3000mm |
|
Machine weight |
800kg |
